Description
Features of DAC Cable 10G
- Supports hot-swappable SFP+ form factor
- Compliant with SFF-8431/SFF-8432
- Compliant with SFP+ MSA and 10GSFP+Cu standards
- Maximum rate up to 10.3125Gbps, backward compatible with 1Gbps
- Connection length up to 7 meters via active copper cable
- Enhanced EMI/EMC performance
- Provide cable sizes from 30AWG to 24AWG
- I2C-based two-wire serial interface with customizable EEPROM signature
- Operating temperature: 0~70℃
- Compliant with RoHS 6.0
Technical parameters
| Product model | SFP-H10GB-CU1M | Brand | Yingda |
| Transmission rate | 10G | Warranty | 3 Years |
| Transmission distance | 1-7m | Cable material | PVC |
| Packaging form | SFP+ to SFP+ | Operating temperature | 0~70℃ |
| Cable type | 30AWG/24AWG | Power supply voltage | 3.3V |
