Description
Features
- Hot-swappable QSFP+ package
- 4-channel full-duplex active optical cable (one 40G QSFP+ module at each end)
- 4-channel 850nm VCSEL laser array and PIN photodetector array
- Compliant with QSFP+ MSA and IEEE 802.3ba 40GBASE-SR4 standards
- Compatible with InfiniBand SDR/DDR/QDR standards
- Maximum rate up to 41.25Gbps
- Interconnection up to 300m can be achieved through OM3 multimode fiber (cable length can be customized)
- The maximum power consumption of each QSFP+ module is less than 1.5W
- Operating temperature: 0-70℃
- Power supply voltage: 3.3V
- Compliant with RoHS6.0
Technical Parameter
| Product model | QSFP-40G-AOC1M | Brand | YINGDA |
| Transmission rate | 40G | Warranty | 3years |
| Transmission distance | 1-100m (optional) | Cable material | PVC |
| Packaging form | QSFP+ to QSFP+ | Operating temperature | 0~70℃ |
| Cable type | OM3&OM4 (optional) | Power | <1W |
