Description
Features
- Box is lock with screw rod+4 brackets
- Total 5 splice tray, each fusion 12cores and 1×8 splitter tube fix slot
- It is applicable for outdoor cables or indoor soft cable
- The box can use for a minimum period of 20 years
- FTTH outdoor wall mounted or pole mount
- Box with waterproof circle, protection class IP65
- High quality ABS+PC plastic, all metal parts stainless steel
- Anti-UV, Ultra violet and rainfall resistant, excellent sealing performance
- Large fiber storage and routing area, reasonable bend radius
Specification
| Model | CTO-16B (FDB0216Y) |
| Dimension (W*D*H) | 345*220*95mm |
| Max. Capacity | 48core=4*12F(single fiber), 1 tray for splitter |
| Cable entry | 1 mid span |
| Cable exit | 16 Huawei Opti-Tap SC adapter output, 1adapter port reserved |
| Cable diameter | 1mid span:φ10-16.5mm |
| Splitter quantity | 2pcs 1×8 or 1pc 1×16 steel tube |
| Color | Grey / black |
