Description
Pigtail Patch Cord Features
- High repeatability and high return loss
- High stability and good interchangeability
- Low insertion loss and high reliability
- Three types of fiber end faces: PC, UPC, APC
- The entire series of optical fibers can be used: multi-mode (50/125, 62.5/125, OM3, OM4, OM5), single-mode (G.652, G.655, G.657, etc.)
Pigtail Patch Cord Application
- Fiber Optic Telecommunications
- LAN (Local Area Network
- FTTH (Fiber To The Home)
- CATV&CCTV
- High speed transmission systems
- Fiber optic sense
Pigtail Patch Cord Specification
| Item | Value |
| Connector | ST |
| Operating wavelength | 1260-1650nm |
| Fiber type | Singlemode 9/125um |
| Cable jacket | LSZH, PVC, PE, TPU, etc. |
| Cable type | Simple Φ0.9mm |
| Polish manner | UPC |
| Cable color | Yellow |
| Fiber radius of curvature | ≥ 40 mm (G.652D and G.655C); ≥ 20 mm (only G.657A2) |
| Insertion Loss | ≤ 0.1dB (Master)≤ 0.3dB (Standard)Tested by JDS RM 3750 |
| Return Loss | UPC ≥ 55dB,APC ≥ 60dB (typ.65dB)–Single mode UPC≥ 35dB (typ.38dB)-Multi mode Tested by JDS RM3750 |
| Repeat ability | ±0.1dB |
| Operating temperature | -40 ° C to 85 ° C |
| Geometry Requirement(For Single mode) | Ferrule End face Radius:7mm ≤ R ≤ 12mm (APC)10mm ≤ R ≤ 25mm (Standard)Apex Offset ≤ 30 μm (Master)Apex Offset ≤ 50 μm (Standard)Undercut -50nm ≤ U ≤ 50nmTested by DORC ZX-1 |
