Description
MT to MPO Fiber Patch Cord Features
- Low insertion loss, high return loss
- Good interchangeability, good repeatability, good temperature stability
- MT can be connected to other fiber connectors, such as MT to FC, MT to SC, MT to ST, etc.
- Loose fiber, ribbon fiber or bundled fiber can be provided
- FA-MT ribbon fiber cable assembly can be provided
- Singlemode and multimode MT ribbon fiber can be provided
- Widely used in fiber optic communication rooms, fiber-to-the-home, fiber optic data transmission, local area network and other equipment
- Fiber count can be from 8 fiber, 12 fiber, 16 fiber, 24 fiber, 32 fiber or 48 fibers.
MT to MPO Fiber Patch Cord Specification
| Item | Elite loss | Standard loss |
| Insertion loss | <0.35 dB | <0.7 dB |
| Return loss | PC>25dB | >25dB |
| Plugging test | 100 times< 0.5 dB | |
| Working temperature | -40～+80 ℃ | |
| Fiber type | OM1/OM2/OM3/OM4/OM5 | |
MT to MPO Fiber Patch Cord Details
For the MT to MPO fiber patch cord, you can add spring or not, depend on your project request. Please specify in advance.
Take off the dust cover for both MT connector, and MPO connector, then can plug into the fiber optic equipment. After unplug, please put on the dust cap to prevent dust.
The MT connector are always used with the MT interface on switch like below, for large bandwidth transmission.
