The duplex armored fiber optic cable is protected by flexible stainless steel spiral tube and freely used like electrical wire. Compared with the regular fiber cable, it is with higher compression & impact resistance, anti-bug. With fixed standard 3mm diameter, there can be 2 fibers inside with fanout kits to add fiber optic connectors SC FC LC ST e2000 MPO MTP, etc, which is widely used in various terrible environment.
| Connector | LC/UPC-LC/UPC |
| Operating wavelength | 1260-1650nm |
| Fiber type | G652D, G657A1 |
| Cable jacket | LSZH, PVC |
| Cable type | Duplex Φ3mm |
| Polish manner | UPC |
| Cable color | Yellow, white, blue |
| Fiber radius of curvature | ≥ 30 mm (G.652D); ≥ 15 mm (G.657A1) |
| Insertion Loss | ≤ 0.3dB (Standard) |
| Return Loss | APC ≥ 60dB (typ.65dB)–Single mode |
| Repeat ability | ±0.1dB |
| Operating temperature | -40 ° C to 85 ° C |
EXW, FOB, CFR, CIF, DDU, DDP, CPT are optional.
TT, Paypal, Escrow, Alipay, Wechat are optional, no credit.
Yingda accept small bulk order, and sample order. If retailer, please consult our fiber optic distributor in local.
Yingda support team working time: 9am-18pm from Monday to Friday, but AI robot will be always online, you can leave message, will get back to you on the first sight your mails.
If urgent, please CHAT ON WhatsApp:+8618688982406
Yingda productivity is high efficiency, very fast. Normally 2-15 days on different quantity. Let's talk for more details.
Yes, we can do pack or assembly like your requirements, please specify details in purchase order.
High productivity efficiency, skilled front-line operators and strict production control ensure timely delivery.
High-precision testing equipment and top industry quality control system ensure high quality standards.
Long-term stable supply chain and cost control that changes in line with market trends ensure the best price
The more details, the better offer, will reply you in 24 hours.
