Description
Features of ODF Patch Panel
- High quality cold rolled steel with spraying
- 16pcs LGX modules can be used in 3U rack height
- Large fiber fusion splicing up to 192 cores single fiber
- Plastic sliding rails for fast operation and installation, no need special tools
Chassis specification
| Model | YDCH-108 |
| Dimension | 430*250*130mm |
| Max capacity | 192 cores |
| Adapter qty | 192 SC |
| LGX modules | 16 pcs 1×8 modules |
| Material | Cold rolled steel |
| Color | White |
| LGX size | 130*100*25mm |
