Description
Features
- High strength metal material, long time use
- 100% qualified test before delivery
- Low insertion loss, high precise ceramic sleeve
simplex, duplex can be optional with different color - Customer logo can be print
- Dust cap type can be customize
Specification
| Item | SC Adapter | |||
| Fiber count | Simplex, Duplex | |||
| Fiber type | SM | MM | ||
| Polish method | PC | UPC | APC | PC |
| Insertion loss | ≤0.2dB | |||
| Alternation loss | ≤0.2dB | |||
| Repeat ability | ≤0.2dB | |||
| Durability | >1000times | |||
| Working temperature | -40 ~+85 ℃ | |||
| Storage temperature | -40 ~+85 ℃ | |||
| Standard | ROHS,Telcordia GR-326-CORE, YD/T-1272.3 standards | |||
| Material | Core: PBT
Housing: ABS Sleeve: Ceramic Clip: Stainless steel 201 |
|||
