SC-UPC Multi Mode OM2 SX Fiber Optic Pigtail – 0.9mm Orange Low-Loss Patch Cord

ST stands for “Stab & Twist”. The ST connector adopts a metal circular bayonet rotating locking structure, with a long floating spring sleeve built-in to fix the optical fiber. After insertion, it can be rotated half a circle and fixed with the bayonet. And it uses high-precision ceramic ferrule, with excellent loss recovery and insertion performance, making it convenient and fast to use.

Description

ST fiber optic pigtails is only with ST connector at one side of the fiber optic cables, the other end is bulk head for fusion splicing. It is widely used in ODF, splice closure, splice tray, cable cross cabinet or fiber patch panels.



Features

  • High repeatability and high return loss
  • High stability and good interchangeability
  • Low insertion loss and high reliability
  • Three types of fiber end faces: PC, UPC, APC
  • The entire series of optical fibers can be used: multi-mode (50/125, 62.5/125, OM3, OM4, OM5), single-mode (G.652, G.655, G.657, etc.)



Application

  • Fiber Optic Telecommunications
  • LAN (Local Area Network
  • FTTH (Fiber To The Home)
  • CATV&CCTV
  • High speed transmission systems
  • Fiber optic sense



Specification

Item Value
Connector SC LC FC ST E2000 DIN D4 SMA FDDI MTRJ MU MPO MTP LX.5 VF45, etc.
Operating wavelength 1260-1650nm
Fiber type G652D, G657A2, G657A1, G655, G657B3, OM1 OM2 OM3 OM4,OM5, etc.
Cable jacket LSZH, PVC, PE, TPU, etc.
Cable type Simplex, duplex (zip cord), Φ3mm,Φ2.6mm, Φ2.4mm, Φ2mm,Φ1.6mm, Φ0.9mm, etc.
Polish manner UPC, APC(8°), PC
Cable color Yellow, white, blue, orange, gray, green, etc.
Fiber radius of curvature ≥ 40 mm (G.652D and G.655C); ≥ 20 mm (only G.657A2)
Insertion Loss ≤ 0.1dB (Master)

≤ 0.3dB (Standard)

Tested by JDS RM 3750

Return Loss UPC ≥ 55dB,APC ≥ 60dB (typ.65dB)–Single mode

UPC≥ 35dB (typ.38dB)-Multi mode

Tested by JDS RM3750

Repeat ability ±0.1dB
Operating temperature -40 ° C to 85 ° C
Geometry Requirement

(For Single mode)

Ferrule End face Radius:

7mm ≤ R ≤ 12mm (APC)

10mm ≤ R ≤ 25mm (Standard)

Apex Offset ≤ 30 μm (Master)

Apex Offset ≤ 50 μm (Standard)

Undercut -50nm ≤ U ≤ 50nm

Tested by DORC ZX-1
