Description
Microduct Reduced Connector Features
- The microducts diameters which will be connected are different;
- Transparent material allows for easy inspection of the connector connection status. Unique structure with locking rings to prevent accidental connector removal and internal cone holes to prevent fiber hang-up.
- Precision structural designensure IP68 waterproof rating, suitable for outdoor underground use.
- Multi size can be choose from 5mmto 3mm, 12mm to 5mm, 12mm to 8mm, 12mm to 10mm, 14mm to 10mm, 14mm to 12mm, 16mm to 14mm,etc.
- Custom colors are available, such as red, blue, or green. If not specified, the product will be subject to the company’s delivery.
Microduct Reduced Connector Specification
| Model | Bigger Port Duct OD/ID (mm) | Smaller Port Duct OD/ID (mm) | Reduction | Pack Qty (pcs/CTN) |
| YDMC-R5/2.1 | 5/3.5 | 3/2.1 | 3.5 to 2.1 | 3000 |
| YDMC-R5/2.8 | 5/3.5 | 4/2.8 | 3.5 to 2.8 | 3000 |
| YDMC-R7/2.1 | 7/5.5 | 3/2.1 | 5.5 to 2.1 | 2000 |
| YDMC-R7/2.8 | 7/5.5 | 4/2.8 | 5.5 to 2.8 | 2000 |
| YDMC-R7/3.5 | 7/5.5 | 5/3.5 | 5.5 to 3.5 | 2000 |
| YDMC-R8/2.1 | 8/6 | 3/2.1 | 6 to 2.1 | 2000 |
| YDMC-R8/3.5 | 8/6 | 5/3.5 | 6 to 3.5 | 2000 |
| YDMC-R8/5.5 | 8/6 | 7/5.5 | 6 to 3.5 | 2000 |
| YDMC-R10/3.5 | 10/8 | 5/3.5 | 8 to 3.5 | 1000 |
| YDMC-R10/5.5 | 10/8 | 7/5.5 | 8 to 5.5 | 1000 |
| YDMC-R10/6 | 10/8 | 8/6 | 8 to 6 | 1000 |
| YDMC-R12/3.5 | 12/10 | 5/3.5 | 10 to 3.5 | 1000 |
| YDMC-R12/5.5 | 12/10 | 7/5.5 | 8 to 5.5 | 1000 |
| YDMC-R12/6 | 12/10 | 8/6 | 8 to 6 | 1000 |
| YDMC-R12/8 | 12/10 | 10/8 | 10 to 8 | 1000 |
| YDMC-R12.7/10 | 12.7/10 | 12/10 | 12.7 to 10 | 1000 |
| YDMC-R14/3.5 | 14/10 | 7/3.5 | 10 to 3.5 | 1000 |
| YDMC-R14/8 | 14/12 | 10/8 | 12 to 8 | 1000 |
| YDMC-R14/10 | 14/12 | 12/10 | 12 to 10 | 1000 |
| YDMC-R16/8 | 16/13 | 10/8 | 13 to 8 | 800 |
| YDMC-R16/1210 | 16/13 | 12/10 | 13 to 10 | 600 |
| YDMC-R16/1410 | 16/13 | 14/10 | 13 to 10 | 600 |
| YDMC-R18/10 | 18/14 | 14/10 | 14 to 10 | 500 |
Microduct Reduced Connector Details
Yingda provide various specifications and sizes of microtube reduced connectors from 3mm, 5mm, 7mm, to 18mm, 20mm, suitable for connecting and protecting various microtubes. Especially suitable for situations where the sizes of microtubules at both ends are not consistent.
In addition to microduct reduced connectors with different sizes at both ends, Yingda manufacturer and wholesale various straight through microduct connectors, microduct end stops. And the product colors that can be customized: blue, red, green, yellow, etc.
Yingda uses high security cardboard boxes to package finished products, ensuring that they will not be damaged during long-term international transportation. All products undergo rigorous testing and inspection, ensuring worry free use for 20 years.
