Description
Features
- Made of high quality cold rolled steel sheet,electrostatic spraying
- Available for small capacity communication system,wall mounting,compact structure,harmonized with machine room
- The cabinet is composed of two parts,one links with optical cables for fusion
- connection between optical cable and fiber pigtail and another links with patch cord.
- Provide fusion and storage for optical cables
- Reliable protection appliance of fixing,stripping and earthing for optical cables.
- Whole range protected design for fiber lay to ensure the bending radius=40mm
- Provide various accessories to avoid any unexpected damage to the fiber
Specification
| Model | GP(05)D-24 |
| Dimension (W*D*H) | 350*300*80mm |
| Max.Capacity | 24cores (single fiber) |
| Cable ports | 2 IN/2OUT |
| Cable diameter | Φ6-Φ24mm |
| Main Material | cold rolled steel 1.0mm |
| Adapter quantity | 24 SC/FC/ST |
