Description
Features
- High quality PC, ABS,PPR material optional, can ensure harsh conditions such as vibration, impact, tensile cable distortion and strong temperature changes.
- Solid structure, perfect outline, thunder, erosion and adding resistance.
- Strong and reasonable structure with mechanical sealing, can be opened after sealing and cab be reused.
- Well water and dust proof, unique grounding device to ensure the sealing performance, convenient for
- The splice closure has a wide application range, with good sealing performance, easy installation, produced with high strength
- Engineering plastic housing, with anti-aging, corrosion resistance, high temperature and high mechanical strength
Application
- Aerial, underground, wall-mounting, duct-mounting, hand hole-mounting.
- The ambient temperature ranges from -40℃ to +65℃.
Dimension and capacity
| Outside dimension (LxWxH) | 430mmⅩ180mmⅩ125mm |
| Weight (excluding outside box) | 2500g-2825g |
| Number of inlet/outlet ports | 3 (pieces) on each side (total 6 pieces) |
| Diameter of fiber cable | Φ8—Φ20 (mm) |
| Capacity of FOSC | Bunchy: 12—96 (Cores) Ribbon: max. 144(Cores) |
