Description
Features
- High quality PC, ABS,PPR material optional, can ensure harsh conditions such as vibration, impact, tensile cable distortion and strong temperature changes.
- Solid structure, perfect outline, thunder, erosion and adding resistance.
- Strong and reasonable structure with mechanical sealing, can be opened after sealing and cab be reused.
- Well water and dust proof, unique grounding device to ensure the sealing performance, convenient for
- The splice closure has a wide application range, with good sealing performance, easy installation, produced with high strength
- Engineering plastic housing, with anti-aging, corrosion resistance, high temperature and high mechanical strength
Application
- Aerial, underground, wall-mounting, duct-mounting, hand hole-mounting.
- The ambient temperature ranges from -40℃ to +65℃.
Specification
| Model | GJS-H009 |
| Dimension (LxWxH) | 470x180x125mm |
| Cable port | 3in 3out |
| Cable diameter | 2 ports×Φ13mm, 2 ports×Φ16mm, 2 ports×Φ20mm |
| Max capacity | 96 cores , ribbon 144cores |
| Capacity of splice tray | 24 cores single fiber |
| Qty of splice tray | 4pcs |
| Net weight | 2.95kg |
| Operating temperature | -40℃~+65℃ |
