Description
Product Feature
- All functional indicators are in line with the national YD1-2004 standard for distribution box.
- Four-in and four-out cable ports; there are 1 large and 6 small circular holes, which can enter and exit the Φ7~Φ22 optical cables.
- The outer box body is made of high-strength engineering plastics. It has features of light weight, high mechanical strength, anti aging, strong corrosion resistance, lightning resistance, and long service life.
- Stacked structure splice tray and independent insulation grounding device make the optical fiber core configuration, expansion and the cable grounding flexible, convenient and safe.
- The splice tray is equipped with splicing slots and a PLC splitter holder, which can be configured at any time according to the needs of direct or divergent connection.
Specification
| MODEL | GJS-801YW |
| Max capacity | 96 cores bunchy fibers |
| Capacity of each tray | 12 cores |
| Max qty of trays | 8 pcs |
| Cable ports | 2 in 2 out |
| Cable diameter | φ22mm |
| Net weight | 0.75kg |
| Material | PP |
