Description
Features
- Made of high strength plastic, outdoor use IP-65Protection level;
- Integrated with stacked up splice trays, maximum 6pcs, each 24cores;
- Fiber bend radius control more than 40mm;
- Lock with buckles, easy to pen and close, full mechanical sealing mechanism;
- 6 cable entrance (3in 3out) for uncut cable go through the box directly;
- Multi function of splitting, splicing, storage and patching in a box;
- Taking off the flipping board, can direct fusion max. 144cores.
Application
- Wall, pole, aerial mounting installation
- FTTH pre-installation and filed installation
Specification
| Model | GJS-2021 |
| Dimension | 300*186.5*59mm |
| Max capacity | 24 cores (single fiber) |
| Splice tray qty | 1 pc |
| Cable ports | 2in 2out uncut ports, 8pcs flat drop cable ports |
| Cable diameter | Uncut port: Ø7-13mm, flat port: 2x3mm |
| Splitter | 1pc 1:8 splitter module |
| Adapter qty | 8 SC simplex |
| Material | PP+GF |
| Color | black |
| Protection level | IP55 |
| Impact resistance strength | IK09 |
