ftth splitter gpon 1×8 without connectors, single mode blue input and output fiber arrays 1.5meter long, corning G657A2 fiber

Yingda’s FTTH Splitter GPON 1×8, built for FTTH networks, features high-precision 1 to 8 optical splitting. With compact design, low insertion loss, and stable performance, it ensures efficient GPON signal distribution, simplifying FTTH deployment and boosting network reliability.

SKU YDPLC-BM-108-NNNN Category Tags , Brand:

Description



FTTH Splitter GPON 1×8 Features

  • Low Insertion loss
  • Low PDL
  • High Return Loss
  • Uniform Power Splitting
  • Compact Design
  • Wide Operating Wavelength
  • Wide Operating Temperature
  • Excellent Environmental & Mechanical Stability
  • Qualified Under Telcordia GR-1221 and GR-1209



FTTH Splitter GPON 1×8 Specification

Parameter Unit Specification (P Grade)
Channel Number 1X8
Operation Wavelength nm 1260~1650
Insertion Loss (Max.) dB 10.7
Uniformity (Max.) dB 1.0
Polarization Dependent Loss dB 0.3
Return Loss dB ≥50
Directivity dB ≥50
Operating Temperature -40~+85
Operating Humidity %RH ≤93
Storage Humidity %RH ≤93



Detailed Display

This is an FTTH Splitter GPON 1×8. It’s packaged in a transparent plastic tray, with two coils of colorful ribbon fibers neatly arranged. Secured by steel pipe packaging, the compact, protective packaging helps prevent fiber damage, facilitating storage and installation in FTTH GPON networks.

ftth splitter gpon 1x8 without connectors, single mode blue input and output fiber arrays 1.5meter long, corning g657a2 fiber
