Description
The series are used in the end termination of residential buildings and villas, to fix and splice with pigtails. Hinge and convenient press pull bottom lock design. Wall mounted with mechanical protection system.
Features
- Made of cold rolled steel sheet, with electrostatic spraying
- With heat shrink sleeve slots on bottom for better protection
- Manage fiber in a reasonable fiber radius condition
- Easy to maintain and extend the capacity
- Fiber bend radius control more than 40mm
- Ftth indoor wall mount installation
- Capacity is 8 cores, and 8 adapter outputs, available for FC SC ST LC adapters
- Color: white/black
Specification
Model | FTB104A | FTB108A |
Dimension (W*D*H) | 115*135*41.5mm | |
Max.Capacity | 4 core | 8core |
Cable ports | 2 round ports | |
Cable diameter | Φ5–10mm | |
Adapter | 4SC | 8SC |
Standard Accessory: expansion screw, sleeve, nylon tie, adapter screw
