The E2000 connector is a push-pull coupling mechanism that includes an automatic metal shutter for dust and laser beam protection. It adopts an integrated design, with simple and fast termination, suitable for high safety and high-power applications. Yingda can provide E2000 connectors, adapters, fiber patch cord and pigtails that are compatible with DIAMOND (r&m) and Huber Suhner.
E2000 Connector Parts:
Dust Cap, Green Outer Housing, Ferrule Assembly, Spring, Stopper, Riveting Ring, Green boot
Optical Specification
| Parameter | E2000 Connector | |||
| Cable diameter | 0.9mm | |||
| Fiber count | Simplex | |||
| Fiber type | Singlemode | Multimode | ||
| Polish mode | PC | UPC | APC | PC |
| Insertion loss | ≤0.25dB | ≤0.25dB | ≤0.25dB | ≤0.25dB |
| Return loss | ≥50dB | ≥55dB | ≥60dB | / |
| operating wavelength | 1310nm, 1550nm | 850nm, 1300nm | ||
| Ferrule Concentricity | ≤1um | ≤4um | ||
| Operating temperature | -40~85°C | |||
| Durability | >1000times | |||
