The E2000 connector is a push-pull coupling mechanism that includes an automatic metal shutter for dust and laser beam protection. It adopts an integrated design, with simple and fast termination, suitable for high safety and high-power applications. Yingda can provide E2000 connectors, adapters, fiber patch cord and pigtails that are compatible with DIAMOND (r&m) and Huber Suhner.
E2000 Connector Parts:
Dust Cap, Violet Outer Housing, Ferrule Assembly, Spring, Stopper, Riveting Ring, Violet boot
Optical Specification
| Parameter | SC Connector | |||
| Cable diameter | 3.0mm | |||
| Fiber count | Simplex | |||
| Fiber type | Singlemode | Multimode | ||
| Polish mode | PC | UPC | APC | PC |
| Insertion loss | ≤0.25dB | ≤0.25dB | ≤0.25dB | ≤0.25dB |
| Return loss | ≥50dB | ≥55dB | ≥60dB | / |
| operating wavelength | 1310nm, 1550nm | 850nm, 1300nm | ||
| Ferrule Concentricity | ≤1um | ≤4um | ||
| Operating temperature | -40~85°C | |||
| Durability | >1000times | |||
EXW, FOB, CFR, CIF, DDU, DDP, CPT are optional.
TT, Paypal, Escrow, Alipay, Wechat are optional, no credit.
Yingda accept small bulk order, and sample order. If retailer, please consult our fiber optic distributor in local.
Yingda support team working time: 9am-18pm from Monday to Friday, but AI robot will be always online, you can leave message, will get back to you on the first sight your mails.
If urgent, please CHAT ON WhatsApp:+8618688982406
Yingda productivity is high efficiency, very fast. Normally 2-15 days on different quantity. Let's talk for more details.
Yes, we can do pack or assembly like your requirements, please specify details in purchase order.
High productivity efficiency, skilled front-line operators and strict production control ensure timely delivery.
High-precision testing equipment and top industry quality control system ensure high quality standards.
Long-term stable supply chain and cost control that changes in line with market trends ensure the best price
The more details, the better offer, will reply you in 24 hours.
