Description
Fiber optic adapter (also called optic adapter, fiber adapter, fiber optic coupler) are designed to connect two optical fiber cables together. It can be simplex, duplex, quad, 6way or 8ways maximum, both sides will insert 2pcs fiber optic connectors such as FC, SC, ST, LC, MTRJ, MPO, MU and E2000 etc. It is widely used in optical fiber distribution frames (ODF), optical distribution box, or splitter closures, cabinets, etc. which can provide superior, stable and reliable optical performance.
E2000 Fiber Adapter Features
- 100% test before delivery
- Easy to use and plug
- Brand new material, good protection package
- Low insertion loss, high return loss
- Fast delivery, large productivity
- Conforms to Telcordia GR-326-CORE standard
- Conforms to YD/T-1272.3 standard
- Good interchangeability and stable optical performance
Specification
| Fiber type | Single mode | Multimode | |
| Polishing mode | UPC | APC | PC |
| Insertion loss | ≤0.2dB | ≤0.2dB | ≤0.2dB |
| Temperature | 1200-1600nm | ||
| Changeability | ≤0.2dB | ||
| Repeatability | ≤0.1dB | ||
| Interchangeability | ≤0.2dB | ||
| Sleeve material | Ceramic or Phosphor bronze | ||
| Working temperature | -40~+85℃ | ||
| Storage temperature | -40~+85℃ | ||
| Mating times | >1000 times | ||
| Standard | Bellcore TA-NWT-001221/001209 | ||
