Custom 10Ge SFP+ Transceiver Module BIDI 1270/1330nm LC single Fiber Single mode 10 km to 120km,LR, ER, ZR range, DDM, -40ºC to +85°C

The 10Gbe SFP+ transceivers are designed for use in 10 Gigabit Ethernet links from 10km to 120km over single mode fiber. The transceivers are compatible with SFP+ MSA and SFF-8472. For further information, please refer to SFP+ MSA and SFF-8472.

Add to cart
SEND INQUIRY
LiveChat
  • CE
  • ISO
  • ROHS
  • Timely Delivery
  • Quality Assurance
  • Best Price

Description

10Gbe SFP+ Transceiver Features

  • Up to 10.6Gbps data links
  • 1270nm DFB Laser and PIN photo-detector for YDSP96-B7310
  • 1330nm DFB Laser and PIN photo-detector for YDSP96-B3710
  • Up to 120km on 9/125µm SMF
  • Simplex LC receptacle optical interface compliant
  • Hot pluggable transceivers
  • All-metal housing for superior EMI performance
  • RoHS6 compliant (lead free)
  • Operating case temperature: Commercial: -5ºC to +70°C;  Extended: -20ºC to +80°C; Industrial: -40ºC to +85°C

SFP+ Transceiver Application

  • 10GBASE-LR/LW 10G Ethernet
  • 10G Fibre Channel
  • 10G SONET
  • Other optical links

SFP+ TransceiverStandards

  • Compliant with SFP+ MSA
  • Compliant with SFF-8472
  • Compatible with IEEE802.3ae

10Gbe SFP+ Transceiver Optical Parameters

Parameter Symbol Min. Typical Max. Unit Note
Transmitter Section
Centre Wavelength λc 1260 1310 1355 nm
Spectral Width(-20dB) Δλ 1 nm
Side Mode Suppression Ratio SMSR 30 dB
Average Optical Power (avg.) Pout -6.0 +0.5 dBm 1
Laser Off Power Poff – – -30 dBm
Extinction Ratio ER 3.5 – – dB 2
Relative Intensity Noise RIN – – -128 dB/Hz
Optical Rise/Fall Time tr / tf – 50 ps 3
Optical Return Loss Tolerance – – 12 dB
Output Optical Eye Compliant with IEEE802.3ae eye masks when filtered 2
Receiver Section
Receiver Center Wavelength λc 1260 1620 nm
Receiver Sensitivity in Average Power Sen -14.4 0.5 dBm 4
Los Assert LOSA -30 – – dBm
Los Dessert LOSD – – -16 dBm
Los Hysteresis LOSH 0.5 – 5 dB
Overload Pin-max – – 0.5 dBm 4
Receiver Reflectance – – -12 dB
Receiver power (damage) – – 1.5 dBm

Note:

  1. The optical power is launched into 9/125µm SMF.
  2. Measured with a PRBS 231-1test pattern @10.3125Gbps.
  3. Unfiltered, 20-80%. Measured with a PRBS 231-1test pattern @10.3125Gbps.
  4. Measured with a PRBS 231-1test pattern @10.3125Gbps, ER=4dB, BER <10-12.

Mechanical Dimension

custom 10ge sfp+ transceiver module bidi 1270/1330nm lc single fiber single mode 10 km to 120km,lr, er, zr range, ddm, 40ºc to +85°c

Order Information

Part Number Product Description
YDSP96-B7310 TX 1270nm, RX 1330nm, 10Gbps, 10km, Bi-Directional Simplex LC SFP+ Transceiver, -5ºC ~ +70ºC, With DDM.
YDSP96-B7310E TX 1270nm, RX 1330nm, 10Gbps, 10km, Bi-Directional Simplex LC SFP+ Transceiver, -20ºC ~ +80ºC, With DDM.
YDSP96-B7310T TX 1270nm, RX 1330nm, 10Gbps, 10km, Bi-Directional Simplex LC SFP+ Transceiver, -40ºC ~ +85ºC, With DDM.
YDSP96-B3710 TX 1330nm, RX 1270nm, 10Gbps, 10km, Bi-Directional Simplex LC SFP+ Transceiver, -5ºC ~ +70ºC, With DDM.
YDSP96-B3710E TX 1330nm, RX 1270nm, 10Gbps, 10km, Bi-Directional Simplex LC SFP+ Transceiver, -20ºC ~ +80ºC, With DDM.
YDSP96-B3710T TX 1330nm, RX 1270nm, 10Gbps, 10km, Bi-Directional Simplex LC SFP+ Transceiver, -40ºC ~ +85ºC, With DDM.
YDSP96-B7320 TX 1270nm, RX 1330nm, 10Gbps, 20km, Bi-Directional Simplex LC SFP+ Transceiver, -5ºC ~ +70ºC, With DDM.
YDSP96-B7320E TX 1270nm, RX 1330nm, 10Gbps, 20km, Bi-Directional Simplex LC SFP+ Transceiver, -20ºC ~ +80ºC, With DDM.
YDSP96-B7320T TX 1270nm, RX 1330nm, 10Gbps, 20km, Bi-Directional Simplex LC SFP+ Transceiver, -40ºC ~ +85ºC, With DDM.
YDSP96-B3720 TX 1330nm, RX 1270nm, 10Gbps, 20km, Bi-Directional Simplex LC SFP+ Transceiver, -5ºC ~ +70ºC, With DDM.
YDSP96-B3720E TX 1330nm, RX 1270nm, 10Gbps, 20km, Bi-Directional Simplex LC SFP+ Transceiver, -20ºC ~ +80ºC, With DDM.
YDSP96-B3720T TX 1330nm, RX 1270nm, 10Gbps, 20km, Bi-Directional Simplex LC SFP+ Transceiver, -40ºC ~ +85ºC, With DDM.
YDSP96-B7340 TX 1270nm, RX 1330nm, 10Gbps, 40km, Bi-Directional Simplex LC SFP+ Transceiver, -5ºC ~ +70ºC, With DDM
YDSP96-B7340E TX 1270nm, RX 1330nm, 10Gbps, 40km, Bi-Directional Simplex LC SFP+ Transceiver, -20ºC ~ +80ºC, With DDM.
YDSP96-B7340T TX 1270nm, RX 1330nm, 10Gbps, 40km, Bi-Directional Simplex LC SFP+ Transceiver, -40ºC ~ +85ºC, With DDM.
YDSP96-B3740 TX 1330nm, RX 1270nm, 10Gbps, 40km, Bi-Directional Simplex LC SFP+ Transceiver, -5ºC ~ +70ºC, With DDM.
YDSP96-B3740E TX 1330nm, RX 1270nm, 10Gbps, 40km, Bi-Directional Simplex LC SFP+ Transceiver, -20ºC ~ +80ºC, With DDM.
YDSP96-B3740T TX 1330nm, RX 1270nm, 10Gbps, 40km, Bi-Directional Simplex LC SFP+ Transceiver, -40ºC ~ +85ºC, With DDM.
YDSP96-B7360 TX 1270nm, RX 1330nm, 10Gbps, 60km, Bi-Directional Simplex LC SFP+ Transceiver, -5ºC ~ +70ºC, With DDM
YDSP96-B7360E TX 1270nm, RX 1330nm, 10Gbps, 60km, Bi-Directional Simplex LC SFP+ Transceiver, -20ºC ~ +80ºC, With DDM.
YDSP96-B7360T TX 1270nm, RX 1330nm, 10Gbps, 60km, Bi-Directional Simplex LC SFP+ Transceiver, -40ºC ~ +85ºC, With DDM.
YDSP96-B3760 TX 1330nm, RX 1270nm, 10Gbps, 60km, Bi-Directional Simplex LC SFP+ Transceiver, -5ºC ~ +70ºC, With DDM.
YDSP96-B3760E TX 1330nm, RX 1270nm, 10Gbps, 60km, Bi-Directional Simplex LC SFP+ Transceiver, -20ºC ~ +80ºC, With DDM.
YDSP96-B3760T TX 1330nm, RX 1270nm, 10Gbps, 60km, Bi-Directional Simplex LC SFP+ Transceiver, -40ºC ~ +85ºC, With DDM.
YDSP96-B4580 TX 1490nm, RX 1550nm, 10Gbps, 80km, Bi-Directional Simplex LC SFP+ Transceiver, -5ºC ~ +70ºC, With DDM
YDSP96-B4580E TX 1490nm, RX 1550nm, 10Gbps, 80km, Bi-Directional Simplex LC SFP+ Transceiver, -20ºC ~ +80ºC, With DDM.
YDSP96-B4580T TX 1490nm, RX 1550nm, 10Gbps, 80km, Bi-Directional Simplex LC SFP+ Transceiver, -40ºC ~ +85ºC, With DDM.
YDSP96-B5480 TX 1550nm, RX 1490nm, 10Gbps, 80km, Bi-Directional Simplex LC SFP+ Transceiver, -5ºC ~ +70ºC, With DDM.
YDSP96-B5480E TX 1550nm, RX 1490nm, 10Gbps, 80km, Bi-Directional Simplex LC SFP+ Transceiver, -20ºC ~ +80ºC, With DDM.
YDSP96-B5480T TX 1550nm, RX 1490nm, 10Gbps, 80km, Bi-Directional Simplex LC SFP+ Transceiver, -40ºC ~ +85ºC, With DDM.
