Description
According to the use of the SMA jumper, the alignment accuracy of the SMA adapter is generally not as strict as that of the SC adapter. SMA jumpers generally only have multi-mode jumpers, so SMA adapters are generally not divided into single-mode and multi-mode. SMA adapters are mostly used in communication equipment, various test instruments, especially military equipment, medical equipment, etc.
Features
- Suitable for all types of JIS connectors, in line with ROSH indicators
- Accurate mechanical dimensions
- Ceramic or copper inner sleeve
- Good repeatability, can be reused more than 500 times
- Low insertion loss, a variety of types
SMA905 Technical Parameter
| Item | SMA905 adapter | |
| Fiber type | SM 9/125um | MM 50/125um |
| MM 62.5/125um | ||
| Insertion Loss | ≤0.3dB | ≤0.3dB |
| Return Loss | UPC≥50dB APC≥60dB | PC≥45dB |
| Body material | metal | |
| Sleeve material | Copper Bronze | |
| Test wavelength | 1310nm,1550nm, 850nm, 1300nm | |
| Repeatability | 0.1dB Max. | |
| Temperature Range | -20℃~+70℃ | |
| Storage temperature | -40℃+85℃ | |
| Operation Times | ≥500 times, change ≤0.20d B | |
| Relative humidity | 95% | |
