Description
Product Features
- The output end adopts a pre connected design, which is plug and play and does not require fusion connection
- Quick insertion enables the fixation and sealing of optical cables outside the joint box, enabling quick installation
- Support the allocation of optical fibers within the same loose tube to different fusion discs
- Support ground and underground installations
- Small size and beautiful appearance
- Meet the explosion-proof requirements of mines
- Protection level IP68
- Digital management: Support AI image recognition and accurately manage ORP resources
specifications
| Wiring capacity (in cores) | 16 |
| Fusion capacity (in cores) | 96 |
| Type of fusion disc | RJP-12-1 |
| Maximum number of fusion discs | 8 |
| Single disc fusion capacity (unit: core) | 12 |
| Tail fiber type | 16SC/APC tail fibers, length 1m, sheath made of LSZHmaterial, and optical fiber made of G.657A1 fiber |
| model | M -16 |
| Fiber optic cable inlet and outlet holes | 1 TJ-T01 adapter Φ 6-18 mm straight through optical cable |
| 2 TJ-F01 adaptations Φ 5-12mm branching optical cable | |
| 16 SC/APC outdoor adapters | |
| Installation method | Wall hanging |
| Application Scenario | mine |
| Dimensions (height x width x depth, in millimeters) | 405*210*150 |
| Packaging size (height x width x depth, unit: mm) | / |
| Net weight in kg | / |
| Gross weight in kg | / |
| Shell material | PP+GF |
| color | black |
| Protection level | IP68 |
| Impact resistance level | IK09 |
| Flame retardant grade | FV2 |
| Antistatic | Meet GB3836.1 |
| RoHS | satisfy |
| Sealing method | mechanical |
| adapter type | SC/APC outdoor adapter |
Environmental parameters
| working temperature | -40 ~+65 |
| Storage temperature | -40 ~+70 |
| Working humidity | 0%~93% (+40 ) |
| pressure | 70 kPa to 106 kPa |
