Description
Features
- Different cable ports can be available, such 1oval+4round, 1oval+6round in heat shrink or mechanical sealing, good in practicality.
- It applies to various ways of bifurcations including bifurcation of uncut cable.
- It applies to the installation of Φ8~18 cable.
- Ribbon cable is available, which can be installed with 6C or 12 C ribbon cable, corresponding max capacity is 432 core, 576 core.
Specification
| Model | GJS-9501-B |
| Dimension | 455*φ230mm |
| Max capacity | 144cores (single fiber), 432/576cores (ribbon) |
| Cable ports | 1oval+4round ports |
| Cable diameter | Oval: φ8-25mm; round:φ8-18mm |
| Material | Body: PP or PP+GF, Tray: ABS |
| Seal material | Vualcanized silicone rubber |
| Tray capacity | 24 cores single fiber |
| Tray quantity | 6pcs |
| IP grade | IP68 |
